1. Introduction

With the gradual commercialization of the fifth-generation mobile networks (5G), the academic community has begun researching the sixth-generation mobile networks (6G). Due to limitations in the coverage of ground information networks, they struggle to meet the wireless access demands in various scenarios, especially in areas such as mountains, oceans, and deserts where infrastructure development is lacking. In comparison, SATellite (SAT) networks possess extensive coverage and can compensate for the shortcomings of ground networks [1–3]. Additionally, aerial nodes such as Unmanned Aerial Vehicles (UAVs) and airships can provide instant network access services for devices that are distant from terrestrial information networks [4–6]. Therefore, 6G networks are gradually evolving towards the direction of Space-Air-Ground integrated networks [6, 7].

UAVs possess characteristics such as maneuverability, rapid mobility, and cost-effectiveness, making them valuable in various military and civilian applications. Clustering multiple UAVs allows them to overcome individual resource limitations, thereby expanding their utilization across different domains. For example, they are widely used in tasks such as exploring dangerous areas and efficiently collecting various types of data. UAVs have become widely used and important aerial nodes. In the UAV-Ground network architecture, UAVs require stable communication and data links to receive commands, transmit data, and maintain contact with the ground control station. However, in certain special scenarios such as ocean shipping, remote area exploration, and disaster-stricken emergency rescue, UAVs may face issues with weak or unavailable communication signals, limiting their operational range and capabilities. Satellite networks have features such as global signal coverage, high flexibility, and high resilience. Combining them with UAV networks can expand the coverage range of UAV networks and enhance the robustness of UAV networks.

The combination of UAV networks and satellite networks currently faces many challenges in terms of security. Satellite networks have characteristics such as highly heterogeneous network structures, significant propagation delays, and unstable communication links, which make them vulnerable to malicious attacks such as message eavesdropping and tampering, impersonation attacks, and unauthorized access [4–6, 8–11]. On the other hand, current research on networking authentication for UAV networks mostly focuses on the networking authentication mechanism between UAVs and ground networks. Moreover, many of these existing schemes suffer from the issue of high signaling overhead between nodes. These schemes are difficult to fully adapt to the Space-Air integrated scenario. Therefore, the secure networking between satellites and UAVs has become a research hotspot.

Considering the characteristics of high latency between nodes, complex network topology, and limited node resources in the Space-Air integrated networks, we propose a secure networking authentication scheme for satellite nodes and UAV nodes in the Space-Air integration scenario, based on elliptic curve public key cryptography and Chebyshev polynomial. It mainly consists of two stages, SAT-HAP networking authentication stage and the SAT-UAV networking authentication stage, which respectively achieve networking authentication between SAT nodes and high altitude platform (HAP) nodes, as well as networking authentication between SAT nodes and UAV nodes assisted by HAP nodes. The contributions of this scheme are as follows:

• (1)

  First, we propose a certificateless networking authentication protocol for satellite nodes and HAP nodes based on elliptic curve cryptography and Chebyshev polynomials. Our protocol enables efficient mutual authentication between SAT and HAP, and secure session key agreement between SAT and HAP based on the Chebyshev polynomial, thereby establishing a secure communication link between SAT and HAP.

• (2)

  Next, we propose a certificateless networking authentication protocol for satellite nodes and UAV nodes based on elliptic curve cryptography and Chebyshev polynomials. In this protocol, efficient mutual authentication and session key agreement are achieved between SAT and UAV, as well as between UAV and HAP. Considering the scenario of the UAV group, in this protocol, the HAP acts as the group leader to aggregate the signaling of the UAVs. Through hierarchical management of UAV-HAP-SAT, it reduces signaling overhead and avoids massive authentication signaling conflicts, making it suitable for the Space-Air integration scenario.

• (3)

  Through informal security analysis and formal security simulation using Scyther, the results indicate that our proposed scheme can achieve mutual authentication, node identity anonymity, key agreement, unlinkability, perfect forward-backward security, resistance against replay attacks, resistance against man-in-the-middle attacks, resistance against impersonation attacks, and other security properties. When compared with existing related schemes, our proposed scheme demonstrates superior security performance. Furthermore, by comparing our scheme with existing schemes in terms of signaling, bandwidth, and computational overhead, the comparative results indicate that our scheme exhibits good performance advantages.

The remaining parts of this article are organized as follows. Section 2 reviews the relevant literature in recent years. Section 3 introduces the Chebyshev polynomial. Section 4 presents the system model, threat model, and requirements. Section 5 introduces the networking authentication scheme proposed by us for UAVs and satellites. In Section 6, we analyze the security of the scheme through informal security analysis and formal security simulation. In Section 7, we analyze the performance of the scheme from three aspects: signaling, bandwidth, and computational overhead. Finally, we present future prospects in Section 8 and conclude in Section 9.

2. Related work

In this section, we will introduce some related research works on node authentication in Space-Air integrated networks.

Semal et al. [12] proposed a secure group authentication protocol for UAVs based on certificateless cryptography. The protocol can achieve secure key provisions for group members and avoid certificate management and key escrow problems. However, it consumes high computational cost due to the use of bilinear pairing operations. Srinivas et al. [13] proposed a lightweight authentication scheme based on temporal credentials, named TCALAS, to achieve mutual authentication and key agreement among the UAV, ground station, and users. In addition, it can ensure the anonymity of the user. However, Ali et al. [14] pointed out that the scheme does not have extendibility and cannot resist the tracking attack. They proposed another improved protocol, named iTCALAS. Alladi et al. [15] proposed two lightweight authentication protocols based on Physical Unclonable Functions (PUF) for UAVs, named SecAuthUAV, including an authentication protocol between the UAV and ground station and another authentication protocol between UAVs. However, they cannot ensure forward/backward security on the session key. Alladi et al. [16] also presented another authentication protocol based on PUF in tri-layered Software-Defined UAV networks, named PARTH. The protocol can achieve authentication among the mini drones, the leader drones, and the ground station. However, the protocol consumes high communication overhead due to multi-round interactions. Lei et al. [17] proposed an optimized lightweight authentication protocol based on the Chinese remainder theorem to achieve mutual authentication among sensor, UAV, access point, and server. The protocol can resist general attacks and ensure forward/backward security. In order to reduce the computational load of resource-constrained nodes, the protocol offloaded the complex computational processes to resource-rich server nodes. In order to resist location forgery attacks on UAVs, Melo et al. [18] proposed a secure identity and location validation scheme based on the signature technology and the rationality detection mechanism of UAV swarm movement. By combining two mechanisms, the protocol can detect intruders who cannot follow the expected trajectory and improve the accuracy of detection of malicious drones.

There are also some other schemes based on blockchain technology to solve high authentication latency for UAVs [19, 20]. However, some problems such as block mining, data anchoring, and fast real-time synchronization of authentication transactions all add to the overall overhead and development difficulty.

These schemes only achieve networking authentication for the communication between the UAV and the ground nodes (such as sensors, ground station, access point, server, et al.). There are few networking authentication schemes involving the UAV and the space nodes. In addition, most of the above authentication schemes have the problems of frequent interactions between nodes and lead to high signaling overhead. However, there is naturally higher time latency in Space-Air integrated networks than that in UAV networks due to the propagation distance. Therefore, the number of interactions is a key factor that affects the performance of the authentication scheme.

3. Background knowledge

3.1. Extended Chebyshev polynomials

Chebyshev polynomials, also known as Chebyshev chaotic mapping, are a sequence of polynomials defined recursively. In this article, we utilize the extended Chebyshev polynomials [21], which is defined as follows:

Let’s set n ∈ Z ^*, x ∈ Z_q ^*, q is a large prime number, the cosine definition of the nth-order extended Chebyshev polynomials is:

$$\begin{array}{c}\hfill {\mathrm{Tn}}_{}(x)=cos(n·arccos(x))(\mathrm{mod}q).\end{array}$$(1)

The recursive formula is as follows:

$$\begin{array}{c}\hfill {\mathrm{Tn}}_{}(x)=(2x{T}_{n-1}(x)-T_{n-2}(x))(\mathrm{mod}q),\end{array}$$(2)

where T₀(x)=1, T₁(x)=x.

Next, we will introduce the commutative property and the challenging problems associated with the extended Chebyshev polynomials that we will be using in our article.

• (1)

  The extended Chebyshev polynomials satisfy the commutative property, as follows:

  $$\begin{array}{c}\hfill {\mathrm{Tm}}_{}\left({\mathrm{Tn}}_{}(x)\right)={\mathrm{Tn}}_{}\left({\mathrm{Tm}}_{}(x)\right).\end{array}$$(3)

• (2)

  The challenging problems related to extended Chebyshev polynomials [22–26] are as follows:

• (a)

  Chebyshev polynomials based discrete logarithm problem: The value of the Chebyshev polynomial as $\mathit{y}={\mathrm{Tn}}_{}(x)modq$, given the knowledge of y, x, and the large prime number q, it is impossible to solve for n in linear time.

• (b)

  Chebyshev polynomials based computational Diffie-Hellman problem: If x, ${\mathrm{Tm}}_{}(x)modq$, and ${\mathrm{Tn}}_{}(x)modq$ are known, it is not possible to compute ${\mathrm{Tm}}_{}({\mathrm{Tn}}_{}(x))modq$ or ${\mathrm{Tn}}_{}({\mathrm{Tm}}_{}(x))modq$ in linear time.

Note: For simplicity, we will abbreviate ${\mathrm{Tm}}_{}(x)modq$ as T_m(x) in the remaining part of the article.

4. System model, threat model, and requirements

4.1. System model

The standalone operational capability of resource-constrained UAVs is relatively low. Therefore, in order to fully leverage the advantages of easy deployment and strong maneuverability of UAVs, they are often deployed in a cluster work mode in practical operations, thereby enhancing the processing capability of the UAV system. Additionally, in certain special scenarios such as ocean shipping, remote area exploration, and emergency rescue, the ground network architecture faces challenges in providing network access for UAVs. Therefore, as shown in Figure 1, we propose a Satellite-UAV networking architecture for the Space-Air integrated networks. In this architecture, UAVs establish secure links with SATellite (SAT) nodes with the help of High Altitude Platform (HAP) nodes, thereby enhancing the system’s coverage range, service capability, and resilience against damage.

• (1)

  UAV Nodes: UAV nodes are terminal devices with limited computing and storage capabilities that perform various tasks in the airspace, such as data collection, monitoring, and image capture. In this architecture, a certain number of UAV nodes can form a homogeneous or heterogeneous UAV cluster network based on the tasks.

• (2)

  HAP Nodes: High-altitude platform nodes, such as airplanes, airships, and balloons, are devices that possess strong computational and storage capabilities, as well as extended endurance.

• (3)

  SAT Nodes: In this model, satellite nodes primarily refer to satellites in Low Earth orbit (LEO) satellite networks. LEO satellite networks operate at a close distance to the Earth’s surface and have short orbital periods.

• (4)

  Registration Center (RC): In our system model, the RC is responsible for the registration of SAT nodes, HAP nodes, and UAV nodes. It maintains the public and private key information of the system and all nodes.

• (5)

  Ground Station (GS): Ground station is used for communication between the ground and satellites.

• (6)

  Terrestrial Control Center (TCC): The TCC is responsible for controlling and managing the satellite network.

• (7)

  Base Station (BS): In this model, the base station primarily serves the purpose of forwarding information between the TCC and RC.

Figure 1. System model

4.2. Threat model

In this paper, we employ the Dolev-Yao model [27] to analyze the security of the proposed protocol. The Dolev-Yao model assumes an open network channel, where adversaries have the ability to eavesdrop, modify, and intercept messages. Within this model, adversaries are capable of executing various protocol attacks, including impersonation attacks, replay attacks, and man-in-the-middle attacks, and so on.

4.3. Security requirements

Considering that there is no secure communication link between SAT nodes, HAP nodes, and UAV nodes, the satellite-UAV networking architecture needs to fulfill the following security requirements to ensure the secure transmission of data over the air interface:

• (1)

  Mutual authentication: Mutual identity authentication is required among the participating UAV nodes, satellite nodes, and HAP nodes to ensure that the nodes involved in forming the satellite-UAV network are legitimate.

• (2)

  Session key agreement: After completing mutual authentication, the nodes need to engage in session key agreement to ensure communication security.

• (3)

  Perfect forward/backward secrecy: Attackers are unable to deduce previous or subsequent session keys even if the long-term secrets used in session key exchange are compromised.

• (4)

  Anonymity and unlinkability: It is necessary to ensure the confidentiality of node identities during the communication process, preventing attackers from linking the same entity’s identity across different communication sessions.

• (5)

  Resistance to various protocol attacks: The system should be capable of defending against replay attacks, reducing the risk of adversaries capturing and replaying expired messages. It should provide protection against man-in-the-middle attacks, preventing attackers from intercepting and tampering with legitimate messages. Additionally, it should offer resistance to impersonation attacks, ensuring that the identities of legitimate entities cannot be forged.

4.4. Performance requirements

We should consider the specific characteristics of the nodes and scenarios, as well as the corresponding performance requirements, as follows:

• (1)

  Limited resources in nodes: The computing resources of the nodes are limited, thus requiring the design of lightweight secure networking protocols to reduce authentication overhead.

• (2)

  High propagation delay: Due to the long distance between UAV and SAT nodes, there is a significant propagation delay. Therefore, it is important to minimize the signaling interactions in the networking authentication protocol.

5. Proposed scheme

This section presents the proposed secure networking authentication scheme for SAT nodes and UAV nodes in the Space-Air integration scenario. The scheme is divided into three stages, including the node registration stage, SAT-HAP networking authentication stage, SAT-UAV networking authentication stage.

5.1. Node registration stage

Nodes (including SAT nodes, HAP nodes, UAV nodes) need to complete the registration process at the RC initially. The specific registration process is illustrated in Figure 2.

• (1)

  First, the RC selects a large prime number q. Then, an elliptic curve E_p(a, b) and a series of points on the curve are chosen to form a cyclic group G of order q. Let P be a generator of this group. RC selects a random number s ∈ ℤ_q ^* as its private key and then computes the public key is:

  $$\begin{array}{c}\hfill \mathrm{PK}=\mathrm{sP}\mathrm{mod}q.\end{array}$$(4)

  Then, RC selects a hash function H. Lastly, the parameters {q, G, P, PK, H} are publicly disclosed to the entire system.

• (2)

  The node A (SAT node, UAV node, and HAP node) generates a random number x_A and computes a partial public key as follows:

  $$\begin{array}{c}\hfill {\mathrm{XA}}_{}={\mathrm{xA}}_{}P\mathrm{mod}q.\end{array}$$(5)

  The node then sends a registration request message (ID_A, X_A) to the RC.

• (3)

  Once RC receives the request, it generates a random number TID_A as the temporary identity for node A. It then generates another random number z_A and computes a partial private key for node A as follows:

  $$\begin{array}{c}\hfill y_{\text{A}}={\mathrm{zA}}_{}+\mathrm{sH}({\mathrm{IDA}}_{},{\mathrm{XA}}_{})\mathrm{mod}q.\end{array}$$(6)

  Furthermore, the RC generates a partial public key for the node:

  $$\begin{array}{c}\hfill Y_{\text{A}}={\mathrm{yA}}_{}P\mathrm{mod}q.\end{array}$$(7)

  RC stores (ID_A,TID_A,y_A,X_A,Y_A), and sends (B, y_A, Y_A, TID_A) to node A in a secure environment, where B is a random number generated by the RC for the subsequent networking authentication process.

• (4)

  Once node A receives the response, it securely stores the private key pair (x_A, y_A). Subsequently, the node A publicly exposes the public key pair (X_A, Y_A) and T_xA(B).

Figure 2. Registration process

5.2. SAT-HAP networking authentication stage

In our architecture, the HAP nodes serve as devices with strong computing and storage capabilities, as well as a longer endurance compared to UAV nodes. HAP, capable of stable hovering at a specified position, is utilized in our scheme to assist in the authentication between UAV nodes and satellite nodes. To accomplish this, the HAP node needs to establish a secure connection with the satellite. In this section, we will introduce how to achieve mutual authentication between the HAP node and the SAT node. The specific process of authentication is depicted in Figure 3.

• (1)

  First, HAP obtains the current timestamp t_h1. Subsequently, HAP selects a random number r₁ and compute T_r1(m), where m = H(TID_SAT). Then, HAP computes the digital signature Jsat:

  $$\begin{array}{c}\hfill c=H(t_{h1},T_{x_{\mathrm{HAP}}}(B),T_{r_1}(m)),\end{array}$$(8)

  $$\begin{array}{c}\hfill \mathrm{Jsat}=x_{\mathrm{HAP}}(X_{\mathrm{SAT}}+Y_{\mathrm{SAT}}+\mathrm{cP})\mathrm{mod}q.\end{array}$$(9)

  Finally, the message (TID_HAP, Jsat, T_r1(m),t_h1) is sent to the SAT node.

• (2)

  After receiving the message, SAT first checks the freshness of the message using the timestamp t_h1. Then, SAT calculates Jsat′ to verify the authenticity of the HAP signature:

  $$\begin{array}{c}\hfill c^{\prime }=H(t_{h_1},T_{x_{\mathrm{HAP}}}(B),T_{r_1}(m)),\end{array}$$(10)

  $$\begin{array}{c}\hfill \mathrm{Jsa}{t}^{\prime }=(x_{\mathrm{SAT}}+y_{\mathrm{SAT}}+c^{\prime })X_{\mathrm{HAP}}\mathrm{mod}q.\end{array}$$(11)

  If Jsat​ = ​Jsat′, SAT considers the signature verification to be successful. Then, SAT derives the temporary session key TSK_HS based on the Chebyshev polynomials using the following equation:

  $${\mathrm{T}\mathrm{S}\mathrm{K}}_{\mathrm{HS}}=T_{x_{\mathrm{S}\mathrm{A}\mathrm{T}}}\left(\right|T_{x_{\mathrm{H}\mathrm{A}\mathrm{P}}}(B)\left|\right)modq$$(12)

  SAT obtains the current timestamp t_s1, selects a random number r₂ and compute T_r2(m), and calculates the authentication response value Rsat:

  $$\begin{array}{c}\hfill \mathrm{Rsat}=H({\mathrm{TSK}}_{\mathrm{HS}},{\mathrm{TID}}_{\mathrm{SAT}},t_{s1},t_{h1},T_{r_2}(m))\\ \hfill \end{array}$$(13)

  Finally, SAT sends (TID_SAT, Rsat, t_s1, T_r2(m)) as the authentication response message to HAP and computes session key ${\mathrm{SK}}_{\mathrm{HS}}=T_{r2}(T_{r1}(m))modq$.

• (3)

  After receiving the message, HAP first checks the freshness of the message using the timestamp t_s1. Then HAP generates a temporary session key TSK_HS by the following equation:

  $$\begin{array}{c}\hfill {\mathrm{TSK}}_{\mathrm{HS}}=T_{x_{\mathrm{HAP}}}\left(T_{x_{\mathrm{SAT}}}(B)\right)\mathrm{mod}q.\end{array}$$(14)

  Then, HAP computes Rsat′ using the temporary session key TSK_HS. If Rsat = Rsat′, it implies that identity authentication is considered successful. Finally, HAP computes ${\mathrm{SK}}_{\mathrm{HS}}=T_{r_2}\left(T_{r_1}(m)\right)modq$.

Figure 3. Satellite-HAP networking authentication process

5.3. SAT-UAV networking authentication stage

After mutual authentication between the HAP and SAT, this section presents a security networking and authentication mechanism for UAV group and satellite networks assisted by the HAP in the Space-Air integration scenario. Firstly, UAV nodes autonomously initiate authentication requests to the HAP. Subsequently, the HAP aggregates and forwards these requests to a SAT node. Finally, these UAV nodes accomplish mutual identity authentication and session key agreement with both the HAP node and SAT node. Specific authentication steps can be found in the flowchart shown in Figure 4.

• (1)

  First, UAV_i obtains the current timestamp t_ui. Subsequently, UAV_i selects a random number r_i and compute T_ri(m), where m = H(TID_SAT). Then UAV_i computes the signatures Jhap_i and Jsat_i to be used for HAP and SAT.

  $${\mathrm{ci}}_{}=H\left(\right|t_{\mathrm{ui}},T_{{\mathrm{xi}}_{}}(B),T_{{\mathrm{ri}}_{}}(m)\left|\right),$$(15) $$J^{\mathrm{hap}}{}_i={\mathrm{xi}}_{}\left(\right|X_{\mathrm{H}\mathrm{A}\mathrm{P}}+Y_{\mathrm{H}\mathrm{A}\mathrm{P}}+{\mathrm{ci}}_{}P\left|\right)modq,$$(16) $$J_{{\mathrm{S}\mathrm{a}\mathrm{t}}_i}={\mathrm{xi}}_{}\left(\right|X_{\mathrm{S}\mathrm{A}\mathrm{T}}+Y_{\mathrm{S}\mathrm{A}\mathrm{T}}+{\mathrm{ci}}_{}P\left|\right)modq.$$(17)

  Finally, the message (TID_i, Jhap_i, Jsat_i, T_ri(m),t_ui) is sent to the HAP node.

• (2)

  After receiving the message, HAP first checks the freshness of the message using the timestamp t_ui. Then, HAP calculates Jhap_i′ to verify the signature:

  $$\begin{array}{c}\hfill {\mathrm{ci}}_{\prime }^{}=H(t_{\mathit{ui}},T_{{\mathrm{xi}}_{}}(B),T_{{\mathrm{ri}}_{}}(m)),\end{array}$$(18) $$\begin{array}{c}\hfill J{\mathrm{hap}}_i^{\prime }=(x_{\mathrm{HAP}}+y_{\mathrm{HAP}}+{\mathrm{ci}}_{\prime }^{}){\mathrm{Xi}}_{}\mathrm{mod}q.\end{array}$$(19)

  If Jhap_i​ = ​Jhap_i′, HAP considers UAV_i to be a trusted node. After a certain time interval, HAP obtains the current timestamp t_H1 and aggregates all the trusted UAV nodes’ signatures using the session key SK_HS that has been previously negotiated with the SAT node. The aggregated result is:

  $$\begin{array}{c}\hfill \mathrm{Jg}=J{\mathrm{sat}}_1\oplus \dots \oplus J{\mathrm{sat}}_n.\end{array}$$(20)

  Finally, HAP sends (Auth, MAC_HAP) to the SAT node, where Auth = Enc(SK_HS, TID₁, …, TID_n, TID_HAP, T_r1(m),…,T_rn(m),Jg, t_u1, …, t_un, t_H1) and MAC_HAP = H(Auth, SK_HS). Auth is generated by HAP using SK_HS for encryption. Auth enables the encrypted transmission of message content. MAC_HAP is a message authentication code based on SK_HS, which ensures the integrity of messages.

• (3)

  After receiving a message, the SAT node first verifies the freshness of the message by checking timestamps t_H1 and t_u1, …, t_un. Then, SAT computes the aggregate signature Jg′ to verify the legitimacy of each UAV node.

  $$c_i^{\mathrm{\text{'}}}=H\left(\right|t_{{\mathrm{ui}}_{}},T_{{\mathrm{xi}}_{}}(B),T_{{\mathrm{ri}}_{}}(m)\left|\right)$$(21) $$J_{\mathrm{S}\mathrm{a}\mathrm{t}}^{\mathrm{\text{'}}}=\left(\right|x_{\mathrm{S}\mathrm{A}\mathrm{T}}+y_{\mathrm{S}\mathrm{A}\mathrm{T}}+c_i^{\mathrm{\text{'}}}\left|\right){\mathrm{Xi}}_{}modq,$$(22) $$J{g}^{\mathrm{\text{'}}}=J{\mathrm{s}\mathrm{a}\mathrm{t}}_1^{\mathrm{\text{'}}}\oplus \dots \oplus J_{{\mathrm{s}\mathrm{a}\mathrm{t}}_n}{}^{\mathrm{\text{'}}}.$$(23)

  If Jg = Jg′ holds, SAT considers each corresponding UAV node to be trusted. Then, SAT derives the temporary session key TSK_si between SAT and UAV_i based on the Chebyshev polynomial using the following equation:

  $${\mathrm{T}\mathrm{S}\mathrm{K}}_{\mathrm{si}}=T_{x\mathrm{S}\mathrm{A}\mathrm{T}}\left(\right|T_{{\mathrm{xi}}_{}}(B)\left|\right)modq$$(24)

  SAT obtains the current timestamp t_S1, selects a random number r_s and compute T_rs(m), where m = H(TID_SAT). Then SAT calculates the authentication response value Rsat_i:

  $$\begin{array}{c}\hfill R{\mathrm{sat}}_i=H({\mathrm{TSK}}_{\mathit{si}},{\mathrm{TID}}_i,{\mathrm{TID}}_{\mathrm{SAT}},t_{S1},t_{u1},T_{{\mathrm{rs}}_{}}(m)).\end{array}$$(25)

  Finally, SAT sends (ResAuth, MAC_SAT) as the authentication response message to HAP and computes session key ${\mathrm{SK}}_{\mathit{si}}=T_{\mathit{rs}}(T_{\mathit{ri}}(m))modq$ between SAT and UAV_i, where ResAuth = Enc(SK_HS, TID₁, …, TID_n, TID_SAT, R_sat1, …, Rsat_n, T_rs(m),t_S1) and MAC_SAT = H(ResAuth, t_H1, SK_HS). ResAuth is generated by SAT using SK_HS for encryption. This enables the encrypted transmission of message content. MAC_SAT is a message authentication code based on SK_HS, which ensures the integrity of messages sent by SAT.

• (4)

  After receiving the message, HAP first determines the freshness of the message by checking the timestamp t_S1. Then, HAP generates a temporary session key TSK_hi by the following equation:

  $$\begin{array}{c}\hfill {\mathrm{TSK}}_{\mathit{hi}}=T_{x_{\mathrm{HAP}}}\left(T_{{\mathrm{xi}}_{}}(B)\right)\mathrm{mod}q.\end{array}$$(26)

  Subsequently, HAP obtains the current timestamp t_H2, selects a random number r_h and compute T_rh(m), where m = H(TID_SAT). Then HAP generates the authentication response value:

  $$\begin{array}{c}\hfill \mathrm{Rha}{\mathrm{pi}}_{}=H({\mathrm{TSK}}_{\mathit{hi}},t_{H2},R{\mathrm{sat}}_i,T_{{\mathrm{rh}}_{}}(m)).\end{array}$$(27)

  Finally, HAP broadcasts this message (TID₁, …, TID_n, TID_HAP, TID_SAT, Rhap₁, …,  Rhap_n, T_rh(m),T_rs(m),t_S1, t_H2) and computes ${\mathrm{SK}}_{\mathit{hi}}=T_{\mathit{rh}}(T_{\mathit{ri}}(m))modq$.

• (5)

  After receiving the message, UAV nodes first determine the freshness of the message based on the t_H2. Then, based on the received parameters, UAV_i nodes generate temporary session keys TSK_hi and TSK_si using the following equations:

  $${\mathrm{T}\mathrm{S}\mathrm{K}}_{\mathrm{hi}}=T_{{\mathrm{xi}}_{}}\left(\right|T_{x_{\mathrm{H}\mathrm{A}\mathrm{P}}}(B)\left|\right)modq$$(28) $${\mathrm{T}\mathrm{S}\mathrm{K}}_{\mathrm{si}}=T_{{\mathrm{xi}}_{}}\left(\right|T_{r\mathrm{S}\mathrm{A}\mathrm{T}}(B)\left|\right)modq$$(29)

  Then, UAV_i computes Rhap_i′ using the session key TSK_hi and TSK_si. If Rhap_i = Rhap_i′, the UAV_i has accomplished mutual identity authentication with HAP and SAT. Finally, UAV_i nodes computes session keys ${\mathrm{SK}}_{\mathit{hi}}=T_{\mathit{ri}}(T_{\mathit{rh}}(m))modq$ and ${\mathrm{SK}}_{\mathit{si}}=T_{\mathit{ri}}(T_{\mathit{rs}}(m))modq$ for HAP and SAT respectively.

Note: After completing the process in these two stages, secure connections have been established among nodes (SAT, HAP, and UAV), and they initiate sessions. Before the end of this session, the SAT node will select different random numbers as the new temporary identities for the UAV and HAP nodes and will select a random number to update the system parameter B. Finally, the SAT will send the aforementioned parameters to the UAV, HAP, and RC.

Figure 4. Satellite-UAV networking authentication process

6. Security analysis

6.1. Informal security analysis

The proposed scheme in this paper primarily includes the SAT-HAP networking authentication stage and the SAT-UAV networking authentication stage. As the principles of the authentication protocols in these two stages are similar, this section primarily analyzes the security of the SAT-UAV networking authentication stage to assess the security of our proposed scheme.

• (1)

  Achieving mutual authentication among SAT, HAP, and UAV nodes: In our scheme, we employ a signature-based authentication mechanism for the authentication of HAP nodes by satellite nodes, authentication of UAV nodes by satellite nodes, and authentication of UAV nodes by HAP nodes. Specifically, HAP and UAV nodes utilize their respective private keys during the signature generation process, ensuring that the signatures cannot be forged by attackers without knowledge of the signer’s private key. Additionally, the recipient’s public key is used during the signature calculation process, thus preventing attackers from conducting man-in-the-middle attacks. Taking the signature Jsat sent by HAP to the SAT as an example, we illustrate how to verify the signature.

  $$\begin{array}{c}\hfill \begin{array}{cc}\hfill J\mathrm{sat}& =x_{\mathrm{HAP}}(X_{\mathrm{SAT}}+Y_{\mathrm{SAT}}+\mathrm{cP})\mathrm{mod}q\hfill \\ \hfill & =x_{\mathrm{HAP}}(x_{\mathrm{SAT}}P+y_{\mathrm{SAT}}P+\mathrm{cP})\mathrm{mod}q\hfill \\ \hfill & =x_{\mathrm{HAP}}(x_{\mathrm{SAT}}+y_{\mathrm{SAT}}+c)P\mathrm{mod}q\hfill \\ \hfill & =X_{\mathrm{HAP}}(x_{\mathrm{SAT}}+x_{\mathrm{SAT}}+c)\mathrm{mod}q.\hfill \end{array}\end{array}$$(30)

  Equation (30) illustrates how SAT utilizes HAP’s public key and SAT’s private key to verify the signature of HAP. From this, the satellite unilaterally authenticates the UAV. Similarly, SAT unilaterally authenticates UAV, and HAP unilaterally authenticates UAV. In the process of HAP authenticating SAT, UAV authenticating HAP, and UAV authenticating SAT, we employ a different mechanism. Let’s illustrate the mechanism using HAP authenticating SAT as an example. After authenticating HAP, the SAT generates an authentication response value Rsat, which is generated using the key ${\mathrm{TSK}}_{\mathrm{HS}}=T_{x_{\mathrm{SAT}}}\left(T_{x_{\mathrm{HAP}}}(B)\right)modq$. The x_SAT in TSK_HS is the SAT’s private key, making it resistant to forgery. Based on the commutative property of Chebyshev polynomials, HAP can calculate ${\mathrm{TSK}}_{\mathit{HS}}=T_{x_{\mathrm{HAP}}}\left(T_{x_{\mathrm{SAT}}}(B)\right)modq$ and verify the SAT’s identity by checking the correctness of Rsat. Similarly, UAV unilaterally authenticates HAP, and UAV unilaterally authenticates SAT. In conclusion, our solution successfully achieves mutual authentication between SAT, HAP and UAV nodes.

• (2)

  Achieving key agreement: We illustrate the key agreement process between HAP and SAT as an example. The agreement of the session key ${\mathrm{SK}}_{\mathrm{HS}}=T_{r_2}\left(T_{r_1}(m)\right)modq=T_{r_2}\left(T_{r_1}(m)\right)modq$ is realized through the Diffie-Hellman (DH) problem based on the Chebyshev polynomial. The value of the session key SH_HS is solely determined by m, the randomly generated r₁ and r₂ from HAP and SAT respectively, as well as the corresponding T_r1(m) and T_r2(m). SAT and HAP can ensure the integrity of T_r1(m), T_r2(m) and authenticate the identity of the sender through private key signature and the hash value based on the temporary key (Rsat). Even when T_r1(m), T_r2(m) and m are known, it is infeasible for an attacker to infer the values of r₁ and r₂ within linear time. HAP and SAT can uniquely derive the same key SH_HS based on T_r1(m), T_r2(m), ensuring the exclusivity of the key derivation process. Similarly, key establishment has been achieved between UAV and SAT, as well as between UAV and HAP.

• (3)

  Perfect forward-backward security: During each session, HAP and SAT will choose new random numbers r₁ and r₂ to generate the session key SK_HS. Additionally, deriving x from T_x(m) and m is extremely difficult. These two factors ensure that even in the event of leakage of the long-term master key, the past session keys or future session keys will not be compromised. This achieves perfect forward and backward secrecy in terms of key security.

• (4)

  Achieving identity anonymity and unlinkability: During the authentication process of the proposed scheme, each participating node adopts a temporary identity, which is refreshed upon session completion. This ensures the attainment of anonymity for node identities within the scheme. Furthermore, in subsequent authentication instances, nodes employ new temporary identities, preventing adversaries from discerning whether the messages originate from the same node. As a result, the scheme achieves the desirable property of unlinkability.

• (5)

  Resilience against replay attacks: Each message in the proposed scheme is equipped with a timestamp, which is protected from tampering by attackers through the use of signatures, hashing based on temporary session keys or session keys. Therefore, it ensures the freshness of each message, thereby preventing the occurrence of replay attacks.

• (6)

  Resilience against man-in-the-middle attacks: In a Man-in-the-Middle Attack, an attacker impersonates an intermediary between the communicating parties during the communication process. The attacker can intercept and manipulate the content of messages without being detected by the communicating parties. In our proposed scheme, the session key agreement process between the two nodes incorporates private key signatures and hash values based on temporary keys to ensure the correspondence between the session key agreement parameters and the identity of the sender. Taking HAP and SAT as an example, the private key signature Jsat guarantees the authenticity of T_r1(m) as provided by HAP, while Rsat ensures the authenticity of T_r2(m) being provided by SAT. So our scheme effectively defends against man-in-the-middle attacks.

• (7)

  Resilience against impersonation attacks: An impersonation attack refers to the act of an attacker impersonating a legitimate node’s identity in order to gain unauthorized access. Our proposed scheme achieves mutual authentication between nodes through the use of private key signatures and hash value based on temporary keys. Taking HAP and SAT as an example, the private key signature Jsat ensures that SAT can authenticate HAP, while Rsat ensures that HAP can authenticate SAT. As a result, attackers are unable to carry out impersonation attacks.

• (8)

  Avoiding third-party trust escrow issues: During the node registration process, RC is only responsible for computing partial public and private keys of the nodes. Since RC does not possess the complete public and private keys of the nodes, it can avoid third-party escrow issues.

Finally, we compared the proposed scheme with other existing schemes in terms of all the aforementioned security properties. As shown in Table 1, our protocol exhibits superior security compared to other schemes.

6.2. Formal security analysis

In this section, we use a tool called Scyther [28] to assess the security of our proposed protocol. Scyther is a formal security analysis tool based on the SPDL language, which supports various threat models, including the Dolev-Yao model used in our paper. We can model the protocol using events, such as using a claim event to describe the security properties of our scheme’s objectives and using send event and recv event to describe the interaction processes in our protocol. Through simulation analysis, we can determine whether our protocol meets the expected security properties.

Figure 5. The verification result of Satellite-HAP networking authentication stage

Figure 6. The verification result of Satellite-UAV networking authentication stage

Due to the node registration stage being executed in a secure environment, we primarily analyze the protocols in two stages: the SAT-HAP networking authentication stage and the SAT-UAV networking authentication stage. In the modeling of the SAT-HAP networking authentication stage, there are two participating roles: hap and sat. In the SAT-UAV networking authentication stage, there are three roles: uav, hap, and sat. Here, uav represents the UAV node, hap represents the HAP node, and sat represents the SAT node. We validate them from five dimensions: Niagree, Nisynch, Weakagree, Alive, and Secret.

As shown in Figures 5 and 6, the Secret indicates that the keys between our HAP and SAT, UAV and HAP, as well as UAV and SAT are secure. The Weakagree and Alive demonstrate that our nodes have achieved mutual authentication. The Niagree and Nisynch ensure the message synchronization among nodes in our scheme. The simulation results verify that the two networking authentication protocols can achieve mutual identity authentication, key establishment, and resist common protocol attacks such as replay attacks and man-in-the-middle attacks.

7. Performance analysis

To achieve secure networking between the SAT node and UAV nodes in the Space-Air integrated networks, our proposed scheme consists of two main stages: the SAT-HAP networking authentication stage and the SAT-UAV networking authentication stage. In this section, we compare our scheme with existing schemes [29–31] in terms of signaling, bandwidth, and computational overhead. To objectively assess the performance impact of each authentication scheme, we assume that after completing a networking authentication between the SAT-UAV node and HAP node, the HAP node assists in conducting group authentication for n UAV nodes, and we calculate the overall overhead during this authentication process.

7.1. Signaling overhead

In the context of Space-Air integrated networks, the large distance between unmanned aerial vehicle (UAV) and satellite nodes results in increased transmission delays. Additionally, due to the clustering nature of UAV operations, the large amount of authentication signaling can potentially lead to signaling conflicts. Moreover, UAV resources are limited, and the transmitted signals are susceptible to interference. Therefore, schemes with lower signaling overhead tend to demonstrate better performance in practical applications.

Figure 7. Comparison of signaling overhead

Figure 8. Comparison of bandwidth overhead

Figure 9. Comparison of computational overhead

Table 2 presents the signaling overhead of our proposed scheme and other relevant schemes. Our SAT-HAP networking authentication stage requires 2 signaling exchanges and the SAT-UAV networking authentication stage requires (n + 3) exchanges. Therefore, the overall signaling overhead of our scheme can be represented as (n + 5) exchanges. Figure 7 illustrates the variation of signaling overhead for each scheme with respect to the number of UAV nodes. In order to present a clearer and more intuitive comparison of our overhead with other schemes, we have employed a logarithmic scale in Figure 7. This approach also applies to Figures 8 and 9. It can be observed that our scheme exhibits better performance in terms of signaling overhead due to the utilization of HAP node aggregation for authentication signaling, which significantly reduces the number of signaling.

7.2. Bandwidth overhead

In achieving security equivalent to AES-128 bit [32], assuming the public key length based on finite field cryptographic system is 3072 bits, and the private key length is 256 bits. The point length on the elliptic curve is 512 bits. For the Hash algorithm, SM3-256 is used to generate the output, and the first 128 bits of the resulting data length are taken as the output value. The encryption algorithm employed is SM4 with an output data length of 128 bits. The output data length for the Chebyshev polynomial is also 128 bits. The length of the random number is defined as 128 bits, and the lengths of the timestamp and identity identifier are 32 bits.

Table 2 presents the bandwidth overhead of our proposed scheme and other relevant schemes. In our scheme, the bandwidth overhead during the SAT-HAP networking authentication stage is 1024 bits, and the bandwidth overhead during the SAT-UAV networking authentication stage is (1728n + 1408)bits. Therefore, the overall bandwidth overhead in the entire process can be represented as (1728n + 2432) bits. Figure 8 illustrates the variation of bandwidth overhead for each scheme with the number of UAV nodes. As shown in the figure, the comparative results indicate that the bandwidth overhead in our scheme performs better compared to other schemes. The utilization of aggregation and broadcasting mechanisms in our approach allows us to reduce redundant parts in messages and effectively decrease bandwidth overhead.

7.3. Computational overhead

We measured the computational overhead using a device with a Core(TM) i7-7500U CPU @ 2.70 GHz processor and utilized the MIRACL cryptographic library. The timings for various operations were tested, including hash operations T_H = 0.002ms, symmetric encryption/decryption T_E/D = 0.004ms, Chebyshev polynomial T_cheb = 0.766ms, modular exponentiation T_exp = 2.808ms, point multiplication T_P = 2.979ms, asymmetric encryption T_asyE = 4.934ms, asymmetric decryption T_asyD = 2.467ms.

The computational overhead of each scheme is shown in Table 3. For our scheme, the computational overhead of the SAT-HAP networking authentication stage is denoted as (6T_H + 6T_chep + 3T_P), and the computational overhead of the SAT-UAV networking authentication stage is denoted as ((9n + 5)T_H + (8n + 5)T_cheb + (6n)T_P + 4T_E/D). Therefore, the total computation cost of our scheme is ((9n + 11)T_H + (8n + 11)T_cheb + (6n + 3)T_P + 4T_E/D). The variation of computational overhead for each scheme with the number of UAV nodes is depicted in Figure 9. According to the results, our proposed scheme demonstrates superior computational overhead compared to the other comparative schemes. The utilization of the Chebyshev polynomial reduces the computational overhead of one-to-many authentication and key agreement between satellite and UAV nodes.

8. Discussion

This paper primarily focuses on designing a networking authentication scheme between UAV and satellite nodes in the Space-Air integrated networks. However, in practical scenarios, UAV nodes have poor endurance capabilities and are influenced by task assignments, resulting in frequent joining and leaving of nodes within the UAV group. Therefore, in the future, it is worth researching security networking authentication schemes for UAV groups and key update schemes for UAV group members.

9. Conclusion

Considering the combination of UAV networks and satellite networks in the Space-Air integration scenario, we propose a secure networking authentication scheme for SAT nodes and UAV nodes based on the elliptic curve public-key cryptography system and Chebyshev polynomial. Through informal security analysis and formal security simulation using Scyther, the results show that the proposed scheme can achieve mutual authentication, key agreement, identity anonymity and unlinkability, perfect forward and backward secrecy, and resistance against various protocol attacks. Performance analysis also demonstrates the superiority of our scheme over existing schemes in terms of signaling, bandwidth, and computational overhead.

Conflict of Interest

The authors declare no conflict of interest.

Data Availability

No data are associated with this article.

Authors’ Contributions

Jin Cao and Hui Li identified the problem of security authentication for satellite and unmanned aerial vehicle (UAV) networking through research on the current status. Jin Cao compiled the latest research status on UAV networking and proposed research directions. Sheng Li and Xiaoping Shi jointly designed this scheme, with Sheng Li completing the node registration stage and SAT-HAP networking authentication stage, Xiaoping Shi completing the SAT-UAV networking authentication stage. Sheng Li conducted the security analysis, and Xiaoping Shi performed the performance analysis.

Acknowledgments

We would like to thank Xiongpeng Ren for providing helpful suggestions during the process of designing the scheme.

Funding

This work is supported by the National Key Research and Development Program of China (No. 2022YFB2902203), the National Natural Science Foundation of China (No. 62172317, No. 62102298) and the Fundamental Research Funds for the Central Universities (No. YJSJ23007).
